Introduction

This demo verifies whether @nervosnetwork/fiber-js can run inside a browser extension.

( fiber-js is a JavaScript wrapper around the Fiber WebAssembly runtime. It starts a Fiber node inside browser workers and exposes JavaScript methods for controlling that node)

Project repository:

Current support status:

  • Chrome / Chromium-based browsers: supported

  • Firefox: not supported for now

  • Safari (macOS): not supported for now

The current demo is mainly designed for Chrome / Chromium Manifest V3 extensions.

Overall Extension Structure

In this demo, fiber-js runs inside a hidden Offscreen Document instead of the popup or a normal web page.

The recommended structure is:


popup / extension page

↓

background service worker

↓

Offscreen Document

↓

fiber-js

In simple terms:

  • popup / extension page: handles the user interface;

  • background service worker: receives requests and forwards messages;

  • Offscreen Document: runs fiber-js;

  • fiber-js: starts the Fiber node and handles related operations.

Why Use an Offscreen Document

The main reason for using an Offscreen Document is to keep fiber-js running in the extension background.

If fiber-js runs in the popup, a normal extension page, or a web page, it may be interrupted when that page is closed. For payments and channel operations, being interrupted midway may cause abnormal states and may even affect transaction results.

An Offscreen Document is not shown to the user, but it can stay alive in the background for a relatively long time. This makes it a better container for running fiber-js.

It also provides a normal page-like window / document environment, which makes it easier to load WASM, Workers, and other resources.

What the Offscreen Document Does

The Offscreen Document is mainly responsible for:

  • loading @nervosnetwork/fiber-js;

  • initializing WASM;

  • creating the Fiber instance;

  • calling fiber.start();

  • storing Fiber runtime state;

  • receiving requests forwarded by the background;

  • returning execution results or error messages.

You can think of it as the background runtime page for fiber-js inside the browser extension.

Extension Call Flow

The call flow for using fiber-js in the extension is roughly as follows:


1. The user opens the popup or extension page

2. The page sends a request to the background service worker

3. The background checks whether the Offscreen Document already exists

4. If it does not exist, the background creates the Offscreen Document

5. The Offscreen Document loads fiber-js

6. A Fiber instance is created

7. fiber.start() is called

8. Later Fiber-related operations are sent to the Offscreen Document through messages

In other words, the popup does not directly hold the Fiber instance.

The popup only sends requests, for example:

  • start Fiber;

  • query status;

  • connect to a peer.

If invoice creation, invoice payment, channel opening, channel closing, and other operations are supported later, the same structure should be used: the popup sends messages, and the Offscreen Document handles the actual fiber-js calls.

Required Configuration

1. Chrome Version and Manifest V3

Offscreen Document requires Chrome 109+ and Manifest V3.

If you write the manifest directly, you can declare the minimum Chrome version:


minimum_chrome_version: "109"

The current demo only targets Chrome / Chromium MV3 extensions. It does not apply to Firefox or Safari.

2. offscreen Permission

Because an Offscreen Document is used, the following permission needs to be declared in the manifest:


permissions: ["offscreen"]

3. WASM and Worker Permissions

fiber-js loads WASM and also uses Workers, so CSP needs to be configured:


content_security_policy: {

extension_pages: "script-src 'self' 'wasm-unsafe-eval'; worker-src 'self'; object-src 'self';"

}

Where:

  • wasm-unsafe-eval: allows WASM to run;

  • worker-src 'self': allows Workers inside the extension package to be loaded.

4. Cross-Origin Isolation Configuration

fiber-js needs to use SharedArrayBuffer in the browser.

In Chrome / Chromium extensions, the following fields need to be added to the manifest:


cross_origin_embedder_policy: {

value: "require-corp"

},

cross_origin_opener_policy: {

value: "same-origin"

}

You can use the following code to check whether the environment meets the requirements:


window.crossOriginIsolated === true

typeof SharedArrayBuffer === "function"

If these two conditions are not met, fiber-js may fail to start properly.

5. Fiber Key Storage

The current demo generates a Fiber key inside the Offscreen Document and stores it in that page’s own localStorage.

The storage key is:


fiber-extension-demo:fiber-key

On subsequent startups, the demo reads this key first to avoid generating a new Fiber node identity every time the popup is opened.

If this key changes on the next startup, fiber-js will treat it as a different node identity. Fiber state, channels, and other data associated with the old key may no longer be usable and may not be recoverable.

Example Manifest Configuration

Full configuration example:


manifest: {

minimum_chrome_version: "109",

permissions: ["offscreen"],

content_security_policy: {

extension_pages: "script-src 'self' 'wasm-unsafe-eval'; worker-src 'self'; object-src 'self';"

},

cross_origin_embedder_policy: {

value: "require-corp"

},

cross_origin_opener_policy: {

value: "same-origin"

}

}

Build Notes

During packaging, make sure that:

  • the .wasm file has been included in the extension package;

  • the Worker file can be loaded by extension pages;

  • the manifest includes the offscreen permission;

  • the manifest includes the WASM, Worker, and cross-origin isolation configurations.

If the .wasm file is missing, the extension may still be installed, but fiber-js may fail to start.

When publishing the demo, it is recommended to clearly mark it as:


Chrome / Chromium MV3 only

Do not mark Firefox and Safari as supported targets.

Memory Usage

Use the browser’s built-in memory tools to inspect the Offscreen Document page.

Current simple test results:

  • initial memory usage is about 135 MB;

  • no obvious memory leak was observed in idle state.

Only the idle scenario has been tested so far.

Further testing is still needed for:

  • long-running usage;

  • repeated starts and stops;

  • repeated connections;

  • channel opening and closing;

  • recovery after abnormal disconnection.

Firefox and Safari (macOS)

Currently, fiber-js cannot run in Firefox or Safari as a browser extension. For normal web pages, if COOP/COEP can make crossOriginIsolated=true, then the SharedArrayBuffer requirement can be satisfied.

The reason is that the browser implementation of fiber-js depends on SharedArrayBuffer to share memory between Workers, and uses Atomics for synchronization. The Web platform only exposes SharedArrayBuffer when crossOriginIsolated=true.

In Chrome / Chromium extensions, cross-origin isolation can be enabled through the extra manifest fields cross_origin_embedder_policy and cross_origin_opener_policy.

MDN’s WebExtension manifest key list does not include descriptions for cross_origin_embedder_policy / cross_origin_opener_policy. Firefox and Safari also do not currently provide equivalent extension manifest fields like Chrome / Chromium does. Therefore, even if a normal web page can satisfy crossOriginIsolated=true, extension pages currently lack an equivalent configuration entry.

Related Firefox community issues:

No clearly corresponding Safari issue has been found yet.
